Seco 02662808 MDT Double End Turning Insert, ANSI Code: LCGF130302-0300-GG CP500, LCGF Insert, Material Grade: M, 1303 Insert, Rectangle Shape, 13 Seat, Neutral Cutting, For Use On Stainless Steel, Carbide, Manufacturer's Grade: CP500
SECO 02662808
$54.39
/ Order multiples of 10 EA
Out of Stock
- Finish/Coating: PVD-TiAlN+TiN Coated
- Insert Style: LCGF
- Insert Size: 1303
- Material: Carbide
- Length: 12.35 mm
- Thickness: 3.9 in
- Corner Radius: 0.2 in
- Manufacturer's Grade: CP500
- Chipbreaker: GG
- Cutting Direction: Neutral
- Finish: PVD
- Material Grade: M
- Maximum Depth of Cut - Metric: 12.3 mm
- Relief Angle: 7 deg
- Seat Size: 13
- Shape: Rectangle
Medium Grooving Applications
Seco Turning Insert | Double End | Series: MDT | LCGF Insert | 1303 Insert | Rectangle Shape | 12.3 mm Maximum Depth of Cut | 3.9 mm Thickness | 12.3 mm Length | 13 Seat | GG Chipbreaker | 0.2 mm Corner Radius | Manufacturer's Grade: CP500 | ANSI Code: LCGF130302-0300-GG CP500 | ISO Code: LCGF130302-0300-GG CP500 | 7 deg Relief Angle | Neutral Cutting Direction | Carbide | PVD-TiAlN+TiN Coated | Material Grade: M | For Use On: Stainless Steel
