Seco Feedmax™ 02691574 SD203A-N Shank Drill, 9 mm Drill - Metric, 0.3543 in Drill - Decimal Inch, Solid Carbide, DLC Coated
SECO 02691574
$255.96
/ EA
Out of Stock
- Drill Bit Size: 0.3543 in
- Drill Bit Size - Metric: 9 mm
- Cutting Direction: Right Hand
- Shank Type: Cylindrical
- Finish/Coating: DLC Coated
- Flute Length: 47 in
- Flute Length - Metric: 47
- Material: Solid Carbide
- Number of Flutes: 2
- Overall Length - Metric: 89 mm
- Point Angle: 140 deg
- Point Type: Self-Centering
- Shank Size: 10 mm Dia x 40 mm L
- Flute Type: Spiral
Seco Feedmax™ is our latest generation of high performance solid carbide drills. They offer a unique combination of state-of-the-art carbide, coating and geometry technology.
- Solid carbide drills combine state-of-the-art carbide, coating and geometry technology into a unique high performance tool
- Designed for high productivity and low cost per hole
- The self-centering geometry provides high hole quality with no need for center drilling operations
- A protective corner chamfer further enhances application security
Standard/Approvals: DIN 6537A
For hole making applications
Seco Feedmax Screw Machine Drill | Series: SD203A-N | Metric | 9 mm Dia | 89 mm Overall Length | 3XD Cutting Depth | 2 Flutes | Spiral Flute | 47 mm Flute Length | 10 mm Dia x 40 mm L Shank | Cylindrical Shank | 140 deg Point | Self-Centering Point | Right Hand Cutting | Solid Carbide Cutting Edge | Solid Carbide | DLC Coated | Applicable Materials: Aluminum and Non-Ferrous Materials
