Seco 02723693 Turning Insert, ANSI Code: TDAB1.21.50 CP500, TDAB Insert, Material Grade: M, 06T0005 Insert, Triangular Shape, 06 Seat, Neutral Cutting, For Use On Stainless Steel, Carbide, Manufacturer's Grade: CP500
SECO 02723693
$27.06
/ Order multiples of 10 EA
Out of Stock
- Finish/Coating: PVD-TiAlN+TiN Coated
- Insert Style: TDAB
- Insert Size: 06T0005
- Material: Carbide
- Length: 6.8 mm
- Thickness: 1.19 in
- Corner Radius: 0.05 in
- Manufacturer's Grade: CP500
- Cutting Direction: Neutral
- Finish: PVD
- Hole Diameter - Decimal: 0.09291 in
- Hole Diameter - Metric: 2.36 mm
- Included Angle: 60 deg
- Inscribed Circle - Metric: 4.06 mm
- Inscribed Circle Size: 4 mm
- Material Grade: M
- Maximum Depth of Cut: 1 in
- Relief Angle: 15 deg
- Seat Size: 06
- Shape: Triangular
- Width: 6.8 mm
For finishing, medium-rough machining and rough machining of super alloys and titanium
Seco Turning Insert | TDAB Insert | 06T0005 Insert | Triangle Shape | 1 mm Maximum Depth of Cut | 4.06 mm Inscribed Circle | 1.19 mm Thickness | 6.8 mm Length | 06 Seat | 0.05 mm Corner Radius | 2.36 mm Diameter Hole | Manufacturer's Grade: CP500 | ANSI Code: TDAB1.21.50 CP500 | ISO Code: TDAB06T0005 CP500 | 60 deg Included Angle | 15 deg Relief Angle | Neutral Cutting Direction | Carbide | PVD-TiAlN+TiN Coated | Material Grade: M | For Use On: Stainless Steel
