Seco 02754865 Turning Insert, ANSI Code: DCMT32.52-MF2 TP1030, DCMT Insert, Material Grade: P, 11T308 Insert, Diamond Shape, 11 Seat, Negative/Positive Rake, Neutral Cutting, For Use On Steel, Carbide, Manufacturer's Grade: TP1030
SECO 02754865
$17.50
/ Order multiples of 10 EA
Out of Stock
- Finish/Coating: Cermet-TiAlSiN Coated
- Insert Style: DCMT
- Insert Size: 11T308
- Material: Carbide
- Length: 11.6 mm
- Thickness: 3.97 in
- Corner Radius: 0.8 in
- Manufacturer's Grade: TP1030
- Chipbreaker: MF2
- Cutting Direction: Neutral
- Finish: Cermet
- Hole Diameter - Decimal: 0.17716 in
- Hole Diameter - Metric: 4.5 mm
- Included Angle: 55 deg
- Inscribed Circle - Metric: 9.5 mm
- Inscribed Circle Size: 9.53 mm
- Material Grade: P
- Maximum Depth of Cut: 3.75 in
- Rake: Negative/Positive
- Relief Angle: 7 deg
- Seat Size: 11
- Shape: Diamond
- Type: Basic Shape;Positive
- Width: 11.6 mm
- T5315 grade fine grained substrate with a modified cobalt content to increase strength
- Thick MT-CVD coating combining the advantages of TiCN and Al2O3 layers
- Special finish for coating
- Versatile material designed primarily for turning gray and ductile cast iron
- Medium to high cutting speeds
- Suitable for continuous and interrupted cut
- Rounded edge
Medium and Finishing
Seco Turning Insert | DCMT Insert | 11T308 Insert | Diamond Shape | 3.75 mm Maximum Depth of Cut | 9.5 mm Inscribed Circle | 3.97 mm Thickness | 11 Seat | Negative/Positive Rake | MF2 Chipbreaker | 0.8 mm Corner Radius | 4.5 mm Diameter Hole | Manufacturer's Grade: TP1030 | ANSI Code: DCMT32.52-MF2 TP1030 | ISO Code: DCMT11T308-MF2 TP1030 | 55 deg Included Angle | 7 deg Relief Angle | Neutral Cutting Direction | Carbide | Cermet-TiAlSiN Coated | Material Grade: P | For Use On: Steel
