Seco 02956322 Turning Insert, ANSI Code: TCMT32.51-MF2 TP2501, TCMT Insert, Material Grade: P, 16T304 Insert, Triangular Shape, 16 Seat, Negative/Positive Rake, Neutral Cutting, For Use On Steel, Carbide, Manufacturer's Grade: TP2501
SECO 02956322
$18.85
/ Order multiples of 10 EA
Out of Stock
- Finish/Coating: CVD-TiCN+Al2O3 Coated
- Insert Size: 16T304
- Material: Carbide
- Thickness: 3.97 in
- Corner Radius: 0.4 in
- Manufacturer's Grade: TP2501
- Chipbreaker: MF2
- Cutting Direction: Neutral
- Hole Diameter - Metric: 4.5 mm
- Included Angle: 60 deg
- Inscribed Circle - Metric: 9.52 mm
- Material Grade: P
- Maximum Depth of Cut: 3.75 in
- Rake: Negative/Positive
- Relief Angle: 7 deg
- Seat Size: 16
- Shape: Triangular
- Excellent surface finish
- Reliable and secure machining, even in roughing applications
- Possibility to optimize using damped Silent Tools™
Medium and Finishing
Seco Turning Insert | TCMT Insert | 16T304 Insert | Triangle Shape | 3.75 mm Maximum Depth of Cut | 9.52 mm Inscribed Circle | 3.97 mm Thickness | 16.5 mm Length | 16 Seat | Negative/Positive Rake | MF2 Chipbreaker | 0.4 mm Corner Radius | 4.5 mm Diameter Hole | Manufacturer's Grade: TP2501 | ANSI Code: TCMT32.51-MF2 TP2501 | ISO Code: TCMT16T304-MF2 TP2501 | 60 deg Included Angle | 7 deg Relief Angle | Neutral Cutting Direction | Carbide | CVD-TiCN+Al2O3 Coated | Material Grade: P | For Use On: Steel
