Seco 02959950 Turning Insert, ANSI Code: DNMG443-M3 TP2501, DNMG Insert, Material Grade: P, 150612 Insert, Diamond Shape, 15 Seat, Negative/Positive Rake, Neutral Cutting, For Use On Steel, Carbide, Manufacturer's Grade: TP2501
SECO 02959950
$26.58
/ Order multiples of 10 EA
In Stock
- Finish/Coating: CVD-TiCN+Al2O3 Coated
- Insert Style: DNMG
- Insert Size: 150612
- Material: Carbide
- Length: 15.500 mm
- Inscribed Circle: 0.5000 in
- Thickness: 6.35 in
- Corner Radius: 3/64 in
- Manufacturer's Grade: TP2501
- Chipbreaker: M3
- Coating: Al2O3
- Coating Process: Duratomic
- Corner Radius - Metric: 1.2 mm
- Cutting Direction: Neutral
- Finish: CVD
- Hole Diameter - Decimal: 0.2028 in
- Hole Diameter - Metric: 5.15 mm
- Included Angle: 55 deg
- Inscribed Circle - Metric: 12.7 mm
- Inscribed Circle Size: 12.7 mm
- Insert Hand: Neutral
- ISO Number: DNMG443-M3 TP2501
- Manufacturer Grade: TP2501
- Material Grade: P
- Maximum Depth of Cut: 5.25 in
- Part Number: 15466
- Primary Workpiece Material: Steel
- Rake: Negative/Positive
- Relief Angle: 0 Degree
- Seat Size: 15
- Secondary Workpiece Material: Cast Iron
- Shape: Diamond
- Type: Negative;Basic Shape
Standard/Approvals:DNMG443-M3 TP2501
Seco Tools 15466 DNMG | 443 | MF5 | TP2501 | Carbide | Turning Insert
