Seco 02959967 Turning Insert, ANSI Code: VNMU2.532-M3 TP1501, VNMU Insert, Material Grade: P, 130408 Insert, Diamond Shape, 13 Seat, Negative/Positive Rake, Neutral Cutting, For Use On Steel, Carbide, Manufacturer's Grade: TP1501
SECO 02959967
$29.38
/ EA
Out of Stock
- Finish/Coating: CVD-TiCN+Al2O3 Coated
- Insert Style: VNMU
- Insert Size: 130408
- Material: Carbide
- Length: 13 mm
- Thickness: 4.76 in
- Corner Radius: 0.8 in
- Manufacturer's Grade: TP1501
- Chipbreaker: M3
- Cutting Direction: Neutral
- Finish: CVD
- Hole Diameter - Decimal: 0.15 in
- Hole Diameter - Metric: 3.81 mm
- Included Angle: 35 deg
- Inscribed Circle - Metric: 7.94 mm
- Inscribed Circle Size: 7.937 mm
- Material Grade: P
- Rake: Negative/Positive
- Relief Angle: 0 deg
- Seat Size: 13
- Shape: Diamond
- Type: Negative;Basic Shape
- Width: 13 mm
- Excellent surface finish
- Reliable and secure machining, even in roughing applications
- Possibility to optimize by using damped Silent Tools™
Medium Applications
Seco Turning Insert | VNMU Insert | 130408 Insert | Diamond Shape | 7.94 mm Inscribed Circle | 4.76 mm Thickness | 13 Seat | Negative/Positive Rake | M3 Chipbreaker | 0.8 mm Corner Radius | 3.81 mm Diameter Hole | Manufacturer's Grade: TP1501 | ANSI Code: VNMU2.532-M3 TP1501 | ISO Code: VNMU130408-M3 TP1501 | 35 deg Included Angle | 0 deg Relief Angle | Neutral Cutting Direction | Carbide | CVD-TiCN+Al2O3 Coated | Material Grade: P | For Use On: Steel
