Seco 02960426 Turning Insert, ANSI Code: SCMT32.52-M3 TP1501, SCMT Insert, Material Grade: P, 09T308 Insert, Squared Shape, 09 Seat, Negative/Positive Rake, Neutral Cutting, For Use On Steel, Carbide, Manufacturer's Grade: TP1501
SECO 02960426
$15.37
/ Order multiples of 10 EA
Out of Stock
- Finish/Coating: CVD-TiCN+Al2O3 Coated
- Insert Style: SCMT
- Insert Size: 09T308
- Material: Carbide
- Length: 9.52 mm
- Thickness: 3.97 in
- Corner Radius: 0.8 in
- Manufacturer's Grade: TP1501
- Chipbreaker: M3
- Cutting Direction: Neutral
- Finish: CVD
- Hole Diameter - Decimal: 0.17716 in
- Hole Diameter - Metric: 4.5 mm
- Included Angle: 90 deg
- Inscribed Circle - Metric: 9.52 mm
- Inscribed Circle Size: 9.52 mm
- Material Grade: P
- Maximum Depth of Cut: 3.75 in
- Rake: Negative/Positive
- Relief Angle: 7 deg
- Seat Size: 09
- Shape: Squared
- Type: Basic Shape;Positive
- Width: 9.52 mm
- Width - Metric: 9.52 mm
- When turning internally or machining slender components, you can rely on the super sharp cutting edges of CoroTurn® 107
- The low cutting forces and precision coolant combined with a broad range of inserts ensures high quality surface finish
- Wiper geometries available for high feeds and high quality surface finish
- Ground, super sharp insert offer for exceptional surface finish
Medium Applications
Seco Turning Insert | SCMT Insert | 09T308 Insert | Square Shape | 3.75 mm Maximum Depth of Cut | 9.52 mm Inscribed Circle | 3.97 mm Thickness | 9.52 mm Width | 9.52 mm Length | 09 Seat | Negative/Positive Rake | M3 Chipbreaker | 0.8 mm Corner Radius | 4.5 mm Diameter Hole | Manufacturer's Grade: TP1501 | ANSI Code: SCMT32.52-M3 TP1501 | ISO Code: SCMT09T308-M3 TP1501 | 90 deg Included Angle | 7 deg Relief Angle | Neutral Cutting Direction | Carbide | CVD-TiCN+Al2O3 Coated | Material Grade: P | For Use On: Steel
