Seco 02960610 Turning Insert, ANSI Code: DNMM443-R4 TP0501, DNMM Insert, Material Grade: P, 150612 Insert, Diamond Shape, 15 Seat, Negative Rake, Neutral Cutting, For Use On Steel, Carbide, Manufacturer's Grade: TP0501
SECO 02960610
$26.58
/ EA
Out of Stock
- Finish/Coating: CVD-TiCN+Al2O3 Coated
- Insert Style: DNMM
- Insert Size: 150612
- Material: Carbide
- Length: 15 mm
- Thickness: 6.35 in
- Corner Radius: 1.2 mm
- Manufacturer's Grade: TP0501
- Chipbreaker: R4
- Corner Radius - Metric: 1.2 mm
- Cutting Direction: Neutral
- Finish: CVD
- Hole Diameter - Decimal: 0.20275 in
- Hole Diameter - Metric: 5.15 mm
- Included Angle: 55 deg
- Inscribed Circle - Metric: 12.7 mm
- Inscribed Circle Size: 12.7 mm
- Material Grade: P
- Maximum Depth of Cut: 5.25 in
- Rake: Negative
- Relief Angle: 0 deg
- Seat Size: 15
- Shape: Diamond
- Type: Negative;Basic Shape
- Width: 15 mm
- When turning internally or machining slender components, you can rely on the super sharp cutting edges of CoroTurn® 107
- The low cutting forces and precision coolant combined with a broad range of inserts ensures high quality surface finish
- Wiper geometries available for high feeds and high quality surface finish
- Ground, super sharp insert offer for exceptional surface finish
Roughing Applications
Seco Turning Insert | DNMM Insert | 150612 Insert | Diamond Shape | 5.25 mm Maximum Depth of Cut | 12.7 mm Inscribed Circle | 6.35 mm Thickness | 15 Seat | Negative Rake | R4 Chipbreaker | 1.2 mm Corner Radius | 5.15 mm Diameter Hole | Manufacturer's Grade: TP0501 | ANSI Code: DNMM443-R4 TP0501 | ISO Code: DNMM150612-R4 TP0501 | 55 deg Included Angle | 0 deg Relief Angle | Neutral Cutting Direction | Carbide | CVD-TiCN+Al2O3 Coated | Material Grade: P | For Use On: Steel
