Seco 02960751 Turning Insert, ANSI Code: SNMG322-M5 TP2501, SNMG Insert, Material Grade: P, 090308 Insert, Squared Shape, 09 Seat, Negative/Positive Rake, Neutral Cutting, For Use On Steel, Carbide, Manufacturer's Grade: TP2501
SECO 02960751
$13.15
/ EA
Out of Stock
- Finish/Coating: CVD-TiCN+Al2O3 Coated
- Insert Style: SNMG
- Insert Size: 090308
- Material: Carbide
- Inscribed Circle: 9.530 mm
- Thickness: 3.18 in
- Corner Radius: 0.8 in
- Manufacturer's Grade: TP2501
- Chipbreaker: M5
- Coating: TiCN/Al2O3
- Coating Process: CVD
- Cutting Direction: Neutral
- Hole Diameter - Metric: 3.81 mm
- Included Angle: 90 deg
- Inscribed Circle - Metric: 9.53 mm
- Insert Hand: Neutral
- Insert Length: 8.700 mm
- ISO Number: SNMG090308-M5 TP2501
- Manufacturer Grade: TP2501
- Material Grade: P
- Maximum Depth of Cut: 3.75 in
- Overall Length: 9.530 mm
- Part Number: 18259
- Primary Workpiece Material: Steel; Stainless Steel; Cast Iron
- Rake: Negative/Positive
- Relief Angle: 0 Degree
- Seat Size: 09
- Shape: Squared
- Width - Metric: 9.53 mm
Standard/Approvals:SNMG090308-M5 TP2501
Seco Tools 18259 SNMG | 322 | M5 | TP2501 | Carbide | Turning Insert
