Seco 02960814 Turning Insert, ANSI Code: LNMX191940-MF TP1501, LNMX Insert, Material Grade: P, 191940 Insert, Rectangle Shape, 19 Seat, Negative/Positive Rake, Neutral Cutting, For Use On Steel, Carbide, Manufacturer's Grade: TP1501
SECO 02960814
$60.13
/ EA
Out of Stock
- Finish/Coating: CVD-TiCN+Al2O3 Coated
- Insert Style: LNMX
- Insert Size: 191940
- Material: Carbide
- Length: 19.05 mm
- Thickness: 19.05 mm
- Corner Radius: 4 mm
- Manufacturer's Grade: TP1501
- Chipbreaker: MF
- Corner Radius - Metric: 4 mm
- Cutting Direction: Neutral
- Finish: CVD
- Hole Diameter - Decimal: 0.25 in
- Hole Diameter - Metric: 6.35 mm
- Included Angle: 90 deg
- Material Grade: P
- Rake: Negative/Positive
- Relief Angle: 0 deg
- Seat Size: 19
- Shape: Rectangle
- Thickness - Metric: 19.05 mm
- Width - Metric: 10 mm
- Versatile parting and grooving
- Cost efficiency with two edges
- Secure and efficient machining
- Profiling inserts for high-precision profiling operations
- Neutral, right- and left-hand style inserts with geometries dedicated for parting off
- Grooving inserts in many widths and with many corner radii
- Inserts for hard part turning at high feed rates
- Blanks for do-it-yourself grinding
Medium and Finishing
Seco Turning Insert | LNMX Insert | 191940 Insert | Rectangle Shape | 19.05 mm Thickness | 10 mm Width | 19.05 mm Length | 19 Seat | Negative/Positive Rake | MF Chipbreaker | 4 mm Corner Radius | 6.35 mm Diameter Hole | Manufacturer's Grade: TP1501 | ANSI Code: LNMX191940-MF TP1501 | ISO Code: LNMX191940-MF TP1501 | 90 deg Included Angle | 0 deg Relief Angle | Neutral Cutting Direction | Carbide | CVD-TiCN+Al2O3 Coated | Material Grade: P | For Use On: Steel
