Seco 02960915 Turning Insert, ANSI Code: DCMT32.51-M3 TP2501, DCMT Insert, Material Grade: P, 11T304 Insert, Diamond Shape, 11 Seat, Negative/Positive Rake, Neutral Cutting, For Use On Steel, Carbide, Manufacturer's Grade: TP2501
SECO 02960915
$17.78
/ Order multiples of 10 EA
Out of Stock
- Finish/Coating: CVD-TiCN+Al2O3 Coated
- Insert Style: DCMT
- Insert Size: 11T304
- Material: Carbide
- Length: 11.600 mm
- Inscribed Circle: 0.3750 in
- Thickness: 3.97 in
- Corner Radius: 0.4 in
- Manufacturer's Grade: TP2501
- Capacity: 11 mm
- Chipbreaker: M3
- Coating: Al2O3
- Coating Process: Duratomic
- Cutting Direction: Neutral
- Finish: CVD
- Hole Diameter - Decimal: 0.1772 in
- Hole Diameter - Metric: 4.5 mm
- Included Angle: 55 deg
- Inscribed Circle - Metric: 9.5 mm
- Inscribed Circle Size: 9.53 mm
- Insert Hand: Neutral
- ISO Number: DCMT 32.51-M3 TP2501
- Manufacturer Grade: TP2501
- Material Grade: P
- Maximum Depth of Cut: 3.75 in
- Part Number: 20298
- Primary Workpiece Material: Steel
- Rake: Negative/Positive
- Relief Angle: 7 deg
- Seat Size: 11
- Secondary Workpiece Material: Cast Iron
- Shape: Diamond
- Type: Basic Shape;Positive
Standard/Approvals:DCMT 32.51-M3 TP2501
Seco Tools 20298 DCMT | 32.5 | M3 | TP2501 | Carbide | Turning Insert
