Seco 03064484 CNMG Insert Turning, CNMG Insert, Diamond Shape, Negative Rake, Neutral Cutting, Carbide, Manufacturer's Grade: TK1501
SECO 03064484
$19.43
/ Order multiples of 10 EA
Out of Stock
- Finish/Coating: Ti(C/N)/Al2O3/Cr
- Material: Carbide
- Length: 12.900 mm
- Inscribed Circle: 12.700 mm
- Thickness: 4.76 in
- Corner Radius: 1.200 mm
- Manufacturer's Grade: TK1501
- Chipbreaker: M5
- Coating: Cermet
- Corner Radius - Metric: 1.2 mm
- Cutting Direction: Neutral
- Hole Diameter - Metric: 5.15 mm
- Included Angle: 80 deg
- Inscribed Circle - Metric: 12.7 mm
- Insert Hand: Right Hand
- Overall Length: 12.900 mm
- Part Number: 46772
- Rake: Negative
- Shape: Diamond
- Width: 0.508 in
INSERT CNMG433-M5 TK1501
