SGS 44687 S-Carb 43MAPR Center Cutting High Performance Long Reach Neck Positive Rake End Mill With Internal Coolant, 12 mm Dia Cutter, 4 mm Corner Radius, 18 mm Length of Cut, 3 Flutes, 12 mm Dia Shank, 83 mm OAL, TiB2 Coated
SGS 44687
$423.25
/ EA
Out of Stock
- Mill Diameter: 12 mm
- Corner Radius: 4 in
- Number of Flutes: 3
- Material: Solid Carbide
- Length of Cut: 18 mm
- Shank Diameter: 12 mm
- Shank Diameter - Decimal: 0.47244 in
- Shank Diameter - Metric: 12 mm
- Overall Length: 83 mm
- Cutting Direction: Right Hand
- Helix Angle: 38 deg
- Cutter Diameter: 12 mm
- Cutter Diameter - Metric: 12 mm
- Diameter: 0.4713 in
- Diameter - Decimal: 0.4713 in
- Finish: TiB2
- Finish/Coating: TiB2 Coated
- Length of Cut - Metric: 18 mm
- Overall Length - Metric: 83 mm
- Series: S-Carb® 43MAPR
- Shank Length: 0.787 in
- Shank Type: Straight
- Type: Center Cutting High Performance Long Reach Neck Positive Rake
- Flute Type: Spiral
- 3 flute design for high feed power roughing
- High feed direct plunge ability
- Through coolant design
- Polished flute design to maximize chip evacuation
- 0.158 in Corner radius
- Positive rake angle
- Internal coolant
- -0.010/-0.050 mm D1, h6 D2 Tolerance
- HAIMER safe-lock
SGS® End Mill | Corner Radius Extended Reach High Performance Metric Square End | Series: 43APRM | 12 mm Cutter Dia | 83 mm Overall Length | 18 mm Maximum Depth of Cut | 3 Flutes | Spiral Flute | 12 mm Shank Dia | Right Hand Cutting | 37 to 40 deg Helix Angle | Straight Shank | 0.7873 in Shank Length | Solid Carbide | TiB2 Coated
